MBS3000 060G3041
| um temp. range | -40 - 185 °F |
| Non-linearity BFSL ±FS [%] | 0,50 % |
| Output sign. type | 4 - 20 mA |
| Overload press. max. | 120,0 bar |
| Overload press. max. | 1.740 psi |
| Pressure conn. HEX | 27,0 |
| Pressure conn. std. | EN 837 |
| Pressure conne. type | G - 1/4 Male |
| Pressure range | 0,00 - 20,00 bar |
| Press. unit ref. | Gauge (relative) |
| Pulse-snubber | No |
| Response time max. | 4 ms |
| Spec. key | MBS 3000-XX11-1AB04 |
| Supply volt. | 10,00 - 30,00 V |
